The login page displays.

3. Click the Main UI Login button.

The main UI login page displays in a new tab.

4. Enter admin as the user name, enter your local device password, and click the Login

button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.

The System Information page displays.

5. Select Security > Traffic Control > Private VLAN > Private VLAN Promiscuous

Interface Configuration.
The Private VLAN Promiscuous Interface Configuration page displays.

6. Select whether to display physical interfaces, LAGs, or both by clicking one of the

following links above the table heading:

• 1 (the unit ID of the switch): Only physical interfaces are displayed. This is the

default setting.

• LAG: Only LAGs are displayed.
• All: Both physical interfaces and LAGs are displayed.

7. Select one or more interfaces by taking one of the following actions:

To configure a single interface, select the check box associated with the port, or

type the port number in the Go To Interface field and click the Go button.

To configure multiple interfaces with the same settings, select the check box

associated with each interface.

The interface that you select must be configured in Promiscuous mode (see Configure
the private VLAN port mode
on page 581).

8. Click the Delete button.

Your settings are saved.

Your settings are saved. The interface is removed from the primary and secondary
VLANs.

9. To save the settings to the running configuration, click the Save icon.
