To configure the PVST and RPVST interface settings:

1. Launch a web browser.

2. In the address field of your web browser, enter the IP address of the switch.

The login page displays.

3. Click the Main UI Login button.

The main UI login page displays in a new tab.

4. Enter admin as the user name, enter your local device password, and click the Login

button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.

The System Information page displays.

5. Select Switching > STP > Advanced > PVST Interface.

The PVST Interface page displays.

6. From the VLAN ID menu, select a VLANs for which STP and PVST or RPVST is already

enabled, or select Other to configure a by entering and a new VLAN ID.

7. Select whether to display physical interfaces, LAGs, or both by clicking one of the

following links above the table heading:

• 1: Only physical interfaces are displayed. This is the default setting.
• LAG: Only LAGs are displayed.
• All: Both physical interfaces and LAGs are displayed.

8. In the Priority field, enter the priority for the interface.

Set this value to a lower number to let the interface forward frames. The priority s
used when the interface is configured as a point-to-point link. The value can be from
0 to 240. The value must be a multiple of 16.

32

16

0

80

64

48

128 (default)

112

96

176

160

144
