To display or delete IP ACL bindings:

1. Launch a web browser.

2. In the address field of your web browser, enter the IP address of the switch.

The login page displays.

3. Click the Main UI Login button.

The main UI login page displays in a new tab.

4. Enter admin as the user name, enter your local device password, and click the Login

button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.

The System Information page displays.

5. Select Security > ACL > Advanced > Binding Table.

The IP ACL Binding Table page displays. The table displays the IP ACL-to-interface
bindings.

6. To delete an IP ACL-to-interface binding, do the following:

a. Select the check box next to the interface.

b. Click the Delete button.

The binding is removed.

7. To save the settings to the running configuration, click the Save icon.

The following table describes the nonconfigurable information displayed.

Table 165. Interface Binding Status information

Description

Field

The selected interface.

Interface

The selected packet filtering direction for the ACL.

Direction

The type of ACL assigned to the selected interface and direction.

ACL Type
