12. From the Exclude Mrouter Interface Mode menu, select to enable or disable the
mrouter interface mode.
This selection specifies the type of information that is forwarded to the upstream
multicast router interface.
If enabled, the interface blocks all unknown multicast data through the mrouter port,
whether the port is configured dynamically or statically. Only MLD PDUs are allowed
to pass through the mrouter port to the upstream router interface.
The default is Enable. If disabled, the interface forwards both unknown multicast
data and MLD PDUs to the upstream multicast router interface.
Note: For information about MLD Plus mode for VLANs, see Configure MLD
snooping for VLANs automatically with MLD Plus mode on page 274.
13. Either add the new VLAN or save the settings for the existing VLAN:
• Add the new VLAN: Click the Add button.
The VLAN is added.
• Save the settings for the existing VLAN: Click the Apply button.
Your settings are saved.
14. To save the settings to the running configuration, click the Save icon.
Remove the MLD snooping querier settings for a VLAN
You can remove the MLD snooping querier settings for a VLAN.
To remove the MLD snooping querier settings for a VLAN:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
The login page displays.
3. Click the Main UI Login button.
The main UI login page displays in a new tab.
4. Enter admin as the user name, enter your local device password, and click the Login
button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.
The System Information page displays.
5. Select Switching > Multicast > MLD Snooping > Querier VLAN Configuration.
The Querier VLAN Configuration page displays.
