The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.

The System Information page displays.

5. Select Routing > IPv6 Multicast > MLD > MLD Groups.

The MLD Groups page displays.

6. To search for IGMP group entries by interface or group, select one of the following

options from the Search menu:

• Interface: Select Interface from the menu, specify the interface in unit/port format

(for example 0/8), and click the Go button.
If the entry exists, the entry is displayed as the first entry, followed by the remaining
entries.

• Group: Select Group from the menu, specify the multicast group IPv6 address,

and click the Go button.
If the entry exists, that entry with the matching group IPv6 address is displayed
as the first entry, followed by the remaining entries. An exact match is required.

7. To refresh the page, click the Refresh button.

The following table describes the nonconfigurable fields on the page.

Table 126. MLD groups information

Description

Field

The interface on which MLD is enabled.

Interface

The IP multicast group address.

Group IP

The IP address of the source of the last membership report that was

received for the IP multicast group address on the interface.

Last Reporter

The period elapsed since this entry was created.

Up Time

The period remaining before this entry is aged out.

Expiry Time

The source filter mode (Include, Exclude, or NA) for the group on the

interface. If the mode is NA, the field is blank.

Filter Mode

The period remaining until the switch determines that no MLD version 1

members are attached to the interface.

Version 1 Host Timer

The compatibility mode (MLDv1 or MLDv2) of the multicast group on the

interface.

Group Compat Mode
