• 4pt 802.3af + Legacy: The port performs a 4-point resistive detection, and if

required, continues with legacy detection.

• Legacy: The port performs legacy detection.

13. From the Timer Schedule menu, select a timer schedule or select None, which is

the default selection.
For information about setting up and configuring PoE timer schedules, see Timer
schedules
on page 144.

14. Click the Apply button.

Your settings are saved.

15. To save the settings to the running configuration, click the Save icon.

The following table describes the nonconfigurable fields on the page.

Table 40. PoE port information

Description

Field

All ports supports high power mode.

High Power

The maximum power in Watts that can be provided by the port.

Max Power (W)

The class defines the range of power that a powered device (PD) is
drawing from the switch. The class definitions are as follows:
0: 0.44W–15.8W

1: 0.44W–3.84W

2: 3.84W–7.2W

3: 6.49W–15.9W

4: 12.95W–30.8W

5: 25.5W–47.0W

6: 51.0W–64.4W

7: 62.0W–81.1W

8: 71.0W–96.5W

Unknown: The class cannot be detected, or no PD is attached to the

port.

Class

The voltage that is delivered to the PD in volts.

Output Voltage (Volts)

The current that is delivered to the PD in mA.

Output Current (mA)

The power that is delivered to the PD in watts.

Output Power (W)
