Mark CoS: Packets are marked by DiffServ with the specified CoS value

before being forwarded. This selection requires that the Mark CoS field is
set. You must select a CoS value from 0 to 7 from the menu.

Mark CoS As Secondary CoS: For these packets, the outer VLAN tag

priority bits are set as the inner VLAN tag priority. That is, for these packets,
the inner VLAN tag CoS is copied to the outer VLAN tag CoS.

Mark IP Precedence: These packets are marked by DiffServ with the

specified IP Precedence value before being forwarded. This selection
requires that the Mark IP Precedence field is set. You must select an IP
precedence value from 0 to 7 from the menu.

Mark IP DSCP: Packets are marked by DiffServ with the specified DSCP

value before being forwarded. This selection requires that the DSCP field
is set. You must either select a DSCP code from the menu or enter an IP
DSCP value from 0 to 63 in the field next to the menu. A value that you
enter in the field overrides any selection from the menu.
The DSCP value is defined as the high-order six bits of the Service Type
octet in the IP header.

12. Click the Apply button.

Your settings are saved.

13. To save the settings to the running configuration, click the Save icon.

The following table describes the nonconfigurable fields on the page.

Table 137. DiffServ policy configuration, policy attributes

Description

Field

The name of the DiffServ policy.

Policy Name

The type of the policy (In or Out).

Policy Type

The class instances that are associated within the policy.

Member Class Name

Rename an existing DiffServ policy

To rename an existing DiffServ policy:

1. Launch a web browser.

2. In the address field of your web browser, enter the IP address of the switch.

The login page displays.

3. Click the Main UI Login button.

The main UI login page displays in a new tab.
