Note: For information about other settings on the page, see Configure IGMP
snooping manually
on page 255.

7. Click the Apply button.

Your settings are saved.

8. To save the settings to the running configuration, click the Save icon.

9. To refresh the page, click the Refresh button.

The following table describes the nonconfigurable fields on the page.

Table 66. IGMP snooping configuration information

Description

Field

The number of multicast control frames that are processed by the switch.

Multicast Control Frame Count

The interfaces on which IGMP snooping is enabled.

Interfaces Enabled for IGMP

Snooping

Indicates if IGMP snooping is globally enabled or disabled on the switch.

Operational Mode

The VLANs on which IGMP snooping is enabled.

VLAN IDs Enabled For IGMP

Snooping

Configure IGMP snooping manually

You can manually configure the settings for IGMP snooping, which is used to build
forwarding lists for IPv4 multicast traffic.

You can also configure IGMP snooping automatically (see Configure IGMP snooping
automatically with IGMP Plus mode
on page 254).

To configure the settings for IGMP snooping manually:

1. Launch a web browser.

2. In the address field of your web browser, enter the IP address of the switch.

The login page displays.

3. Click the Main UI Login button.

The main UI login page displays in a new tab.

4. Enter admin as the user name, enter your local device password, and click the Login

button.

Main User Manual

255

Configure Switching Information

AV Line of Fully Managed Switches M4250 Series Main User Manual
