M4250-40g8f-poe+ (sku gsm4248p) – NETGEAR AV Line M4250 GSM4210PX 8-Port Gigabit PoE+ Compliant Managed AV Switch with SFP (220W) User Manual

Page 822

background image

Table 188. Hardware technical specifications for model M4250-26G4F-PoE++

Description

Feature

24 PoE++ (802.3bt) 1GBASE-T RJ-45 ports
Two 1GBASE-T RJ-45 ports
Four 1G SFP fiber uplink ports

Network interfaces

100–240V ~ 50–60Hz, 10A for each PSU

AC power input

1 PSU: 889W - 3035.05 BTU/hr
2 PSUs: 1734W - 5919.88 BTU/hr
48.8W - 166.6 BTU/hr
36.9W - 125.98 BTU/hr

Max PoE
No PoE
Standby

Power
consumption

1440W with 2 PSUs

PoE power budget

17.32 in (440 mm)
1.70 in (43.2 mm), 1U
15.75 in (400 mm)

Width
Height
Depth

Dimensions

14.87 lb (6.746 kg)

Weight

M4250-40G8F-PoE+ (SKU GSM4248P)

The following table shows the specifications that are specific to model
M4250-40G8F-PoE+.

Table 189. Hardware technical specifications for model M4250-40G8F-PoE+

Description

Feature

40 PoE+ (802.3at) 1GBASE-T RJ-45 ports
Eight 1G SFP fiber uplink ports

Network interfaces

100–240V ~ 50–60Hz, 6.7–2.6A

AC power input

624.8W - 2133.07 BTU/hr
59.5W - 203.13 BTU/hr
46.4W - 158.41 BTU/hr

Max PoE
No PoE
Standby

Power
consumption

480W

PoE power budget

Main User Manual

822

Software Default Settings and
Hardware Specifications

AV Line of Fully Managed Switches M4250 Series Main User Manual
