Page 340
Table 92. Learned routes information
Description
Field
The IP route prefix for the destination.
Network Address
The subnet/network mask, which indicates the portion of the IP interface
address that identifies the attached network.
Subnet Mask
The protocol that created the route: Local, Static, or RIP.
Protocol
The type of route, depending on the protocol: Connected, Static, or
Dynamic.
Route Type
The interface of the outgoing router interface that must be used when
traffic is forwarded to the destination.
Next Hop Interface
The IP address of the outgoing router interface that must be used when
traffic is forwarded to the next router (if any) in the path toward the
destination.
Next Hop Address
The preference, which is a value from 0 to 255.
Preference
The administrative cost of the path to the destination. The default is 1.
The range is from 0 to 255.
Metric
Delete a route
You can delete a route that you no longer need.
To delete a route:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
The login page displays.
3. Click the Main UI Login button.
The main UI login page displays in a new tab.
4. Enter admin as the user name, enter your local device password, and click the Login
button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.
The System Information page displays.
5. Select Routing > Routing Table > Basic > Route Configuration.
The Route Configuration page displays.
