To configure a single interface, select the check box associated with the interface,

or type the interface number in the Go To Interface field and click the Go button.

To configure multiple interfaces with the same settings, select the check box

associated with each interface.

To configure all interfaces with the same settings, select the check box in the

heading row.

8. From the Admin Mode menu, select Enable or Disable to enable or disable PIM

for the interface.
The default is Disable.

9. In the Hello Interval field, specify the period in seconds between the transmission

of PIM hello messages on the interface.
The range is from 0 to 18000. The default is 30.

10. In the Join/Prune Interval field, specify period in seconds at which PIM Join/Prune

messages are transmitted on the interface.
The range is from 0 to 18000. The default is 60.

11. From the BSR Border menu, select Enable or Disable to enable or disable the

bootstrap router (BSR) border on the interface.
The default is Disable.

12. In the DR Priority field, specify the designated router (DR) priority for the interface.

The range is from 0 to 2147483647. The default is 1.

13. Click the Apply button.

Your settings are saved.

14. To save the settings to the running configuration, click the Save icon.

The following table describes the nonconfigurable field on the page.

Table 117. IPv4 PIM interface configuration information

Description

Field

The state of PIM on the interface (Operational or Non-Operational).

Protocol State

The IPv4 address of the PIM interface.

IP Address
