4. Enter admin as the user name, enter your local device password, and click the Login

button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.

The System Information page displays.

5. Select QoS > DiffServ > Basic > DiffServ Configuration.

The DiffServ Configuration page displays.

6. Select the administrative mode for DiffServ:

• Enable: Differentiated services are active. This is the default setting.
• Disable: Differentiated services are inactive. An existing DiffServ configuration is

retained and can be changed but is not active.

7. Click the Apply button.

Your settings are saved.

8. To save the settings to the running configuration, click the Save icon.

The following table describes the nonconfigurable fields on the page.

Table 134. DiffServ Status information

Description

Field

The number of configured DiffServ classes out of the total allowed on the switch.

Class table

The number of configured class rules out of the total allowed on the switch.

Class Rule table

The number of configured policies out of the total allowed on the switch.

Policy table

The number of configured policy class instances out of the total allowed on the
switch.

Policy Instance table

The number of configured policy attributes (attached to the policy class instances)
out of the total allowed on the switch.

Policy Attributes table

The number of configured services (attached to the policies on specified interfaces)
out of the total allowed on the switch.

Service table

Configure a DiffServ class

You can add a new DiffServ class name or rename or delete an existing class. You can
also define the criteria to associate with a DiffServ class. As packets are received, these
DiffServ classes are used to prioritize packets. You can use multiple match criteria in a
class. The logic is a Boolean logical-AND for this criteria.
