4. Enter admin as the user name, enter your local device password, and click the Login

button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.

The System Information page displays.

5. Select Switching > STP > Advanced > MST Port Configuration.

The MST Port Configuration page displays.

6. From the Select MST menu, select an MST instance.

For information about adding MST instances, see Manage MST instances on page
236.

7. Select whether to display physical interfaces, LAGs, or both by clicking one of the

following links above the table heading:

• 1: Only physical interfaces are displayed. This is the default setting.
• LAG: Only LAGs are displayed.
• All: Both physical interfaces and LAGs are displayed.

8. Select one or more interfaces by taking one of the following actions:

To configure a single interface, select the check box associated with the port, or

type the port number in the Go To Interface field and click the Go button.

To configure multiple interfaces with the same settings, select the check box

associated with each interface.

To configure all interfaces with the same settings, select the check box in the

heading row.

9. Configure the MST values for the selected interface or interfaces:

• Port Priority: In the Port Priority field, specify the priority for the interface in the

MST instance. The port priority is set in multiples of 16. If you specify a value that
is not a multiple of 16, the priority is automatically set to the next lowest priority
that is a multiple of 16. For example, if you set a value between 0 and 15, the
priority is set to 0. If you specify a number between 16 and 31, the priority is set
to 16. Specify a value in the range from 0 to 240. The default is 128.

• Port Path Cost: In the Port Path Cost field, specify the path cost in the range

from 0 to 200000000. The default is 0.

10. Click the Apply button.

Your settings are saved.

11. To save the settings to the running configuration, click the Save icon.
