The Private VLAN Isolated Trunk Interface Configuration page displays.
6. From the Interface menu, select an interface or LAG for which you configured the
VLAN port mode as Isolated Trunk mode.
For more information about port VLAN modes, see Configure the private VLAN port
mode on page 581.
7. In the Isolated Trunk Primary VLAN field, specify a primary VLAN ID.
You can select a VLAN for which you configured the type as Primary (see Assign a
private VLAN type to a VLAN on page 578).
8. In the Isolated Trunk Secondary VLAN(s) field, specify one or more secondary
VLAN IDs.
You can specify VLANs for which you configured the type as Isolated or Community,
both of which are secondary VLAN types within a private VLAN (see Assign a private
VLAN type to a VLAN on page 578).
You can specify a single VLAN ID, a range of VLAN IDs, or a combination of both in
sequence separated by a comma (,):
• You can specify individual VLAN ID, such as 10.
• You can specify the VLAN range values separated by a hyphen, for example,
10-13.
• You can specify the combination of both separated by commas, for example:
12,15,40–43,1000–1005, 2000.
Note: The VLAN IDs that you specify overwrites the secondary VLANs that you
configured on the Private VLAN Association Configuration page (see Configure a
private VLAN association with a primary and secondary VLAN on page 579).
9. Click the Apply button.
Your settings are saved.
The Operational VLAN(s) fields shows the primary and secondary VLANs that operate
on the isolated trunk interface.
10. To save the settings to the running configuration, click the Save icon.
Private VLAN isolated trunk interface: Remove primary and
secondary VLANs from the trunk
You can remove primary and secondary VLANs from a private VLAN isolated trunk
interface.
