Table 125. MLD routing interface statistics information
Description
Field
The interface on which MLD is enabled.
Interface
Indicates if the interface is an MLD querier or non-querier on the IPv6
subnet it is associated with.
Querier Status
The IPv6 address of the MLD querier on the IPv6 subnet to which the
interface is attached.
Querier IP
The period in seconds since the MLD interface querier was last changed.
Querier Up Time
The period in seconds remaining before the other querier present timer
expires. If the switch is the querier, this is zero.
Querier Expiry Time
The number of queries that were received on the interface with an MLD
version that does not match the MLD version configured for the interface
Wrong Version Queries Received
The number of times a group membership was added on the interface;
that is, the number of times an entry for the interface was added to the
cache table.
Number of Joins Received
The current number of entries for the interface in the cache table.
Number of Groups
Display the MLD groups and search the MLD group
database
You can display the MLD group information and search the MLD group database by
interface or by group.
To display the MLD groups and search the MLD group database:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
The login page displays.
3. Click the Main UI Login button.
The main UI login page displays in a new tab.
4. Enter admin as the user name, enter your local device password, and click the Login
button.
