Multiple steps are involved in defining an IPv4 ACL and applying it to the switch:
1. Add an IPv4 ACL ID (see Add an IPv4 ACL on page 664).
The differences between a basic IPv4 ACL and an extended IPv4 ACL are as follows:
• Numbered ACL from 1 to 99: Creates a basic IPv4 ACL, which allows you to
permit or deny traffic from a source IP address.
• Numbered ACL from 100 to 199: Creates an extended IPv4 ACL, which allows
you to permit or deny specific types of Layer 3 or Layer 4 traffic from a source IP
address to a destination IP address. This type of ACL provides more granularity
and filtering capabilities than the basic IP ACL.
• Named IP ACL: Creates an extended IPv4 ACL with a name string that is up to
31 alphanumeric characters in length. The name must start with an alphabetic
character.
2. Create an IPv4 rule (see Configure rules for a basic IP ACL on page 666 or Configure
rules for an extended IPv4 ACL on page 671).
3. Associate the IPv4 ACL with one or more interfaces (see Configure IP ACL interface
bindings on page 688).
You can display or delete IPv4 ACL configurations in the IP ACL Binding table (see
Display or delete IP ACL bindings in the IP ACL binding table on page 690.
Add an IPv4 ACL To add an IPv4 ACL:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
The login page displays.
3. Click the Main UI Login button.
The main UI login page displays in a new tab.
4. Enter admin as the user name, enter your local device password, and click the Login
button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.
The System Information page displays.
5. Select Security > ACL > Advanced > IP ACL.
The IP ACL page displays.
The IP ACL page shows the current size of the ACL table compared to the maximum
size of the ACL table. The current size is equal to the number of configured IPv4
ACLs plus the number of configured MAC ACLs and IPv6 ACLs. The maximum
number of ACLs on the switch is 100.
Main User Manual 664 Manage Switch Security
AV Line of Fully Managed Switches M4250 Series Main User Manual
