Remove a static ipv6 source guard binding – NETGEAR AV Line M4250 GSM4210PX 8-Port Gigabit PoE+ Compliant Managed AV Switch with SFP (220W) User Manual
Page 622
Description
Field
The interface on which the IPv6SG source binding was learned.
Interface
The MAC address associated with the IPv6SG source device. This is the key to the
binding database.
MAC Address
The VLAN ID for the interface of the IPv6SG source device.
VLAN ID
The IPv6 address of the IPv6SG source device.
IPv6 Address
The filter type used on the switch interface. Either IPv6SG is configured to function
with the source IPv6 address only or, if port security is also enabled for IPv6SG, with
both the source IPv6 address and MAC address.
Filter Type
11. To save the settings to the running configuration, click the Save icon.
12. To clear all dynamic bindings from the Dynamic Binding Configuration table, click
the Clear button.
13. To save the settings to the running configuration, click the Save icon.
Remove a static IPv6 source guard binding
You can remove a static binding from the IPv6 source guard (IPv6SG) bindings database.
To remove a static IPv6SG binding:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
The login page displays.
3. Click the Main UI Login button.
The main UI login page displays in a new tab.
4. Enter admin as the user name, enter your local device password, and click the Login
button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.
The System Information page displays.
5. Select Security > Control > IPv6 Source Guard > Binding Configuration.
The Binding Configuration page displays.
6. In the Static Binding Configuration table, select the check box for the static binding.
7. Click the Delete button.
