The main UI login page displays in a new tab.

4. Enter admin as the user name, enter your local device password, and click the Login

button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.

The System Information page displays.

5. Select Routing > IPv6 Multicast > Mroute Table.

The Mroute Table page displays.

6. To refresh the page, click the Refresh button.

The following table describes the nonconfigurable fields on the page.

Table 120. Multicast IPv6 Mroute table information

Description

Field

The destination group IPv6 address.

Group IP

The IPv6 address of the multicast packet source to be combined with the group

IPv6 to fully identify the single route.

Source IP

The incoming interface on which multicast packets for this source/group arrive.

Incoming Interface

The list of outgoing interfaces on which multicast packets for this source/group

are forwarded.

Outgoing Interfaces

The time in seconds since the entry was created.

Up Time (hh:mm:ss)

The time in seconds before this entry ages out and is removed from the table.

Expiry Time (hh:mm:ss)

The IPv6 address of the reverse path forwarding (RPF) neighbor.

RPF Neighbor
