Display the DAI statistics

To display the DAI statistics:

1. Launch a web browser.

2. In the address field of your web browser, enter the IP address of the switch.

The login page displays.

3. Click the Main UI Login button.

The main UI login page displays in a new tab.

4. Enter admin as the user name, enter your local device password, and click the Login

button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.

The System Information page displays.

5. Select Security > Control > Dynamic ARP Inspection > DAI Statistics.

The DAI Statistic page displays.

6. To refresh the page, click the Refresh button.

7. To clear the DAI statistics, click the Clear button.

8. To save the settings to the running configuration, click the Save icon.

The following table describes the nonconfigurable information displayed on the page.

Table 157. DAI Statistics information

Description

Field

The VLAN ID.

VLAN

The number of ARP packets that were dropped by DAI because no matching DHCP
snooping binding entry exists.

DHCP Drops

The number of ARP packets that were forwarded by DAI because a matching DHCP
snooping binding entry exists.

DHCP Permits

The number of ARP packets that were dropped by DAI because no matching ARP ACL
rule exists for the VLAN and the static flag is set on the VLAN.

ACL Drops

The number of ARP packets that were permitted by DAI because a matching ARP ACL
rule exists for the VLAN.

ACL Permits
