Delete an extended IPv4 ACL rule
To delete an extended IPv4 ACL rule:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
The login page displays.
3. Click the Main UI Login button.
The main UI login page displays in a new tab.
4. Enter admin as the user name, enter your local device password, and click the Login
button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.
The System Information page displays.
5. Select Security > ACL > Advanced > IP Extended Rules.
The IP Extended Rules page displays.
6. From the ACL ID/Name menu, select the ACL that includes the rule that you want
to delete.
7. In the Extended ACL Rule Table, select the check box that is associated with the rule.
8. Click the Delete button.
The rule is removed.
9. To save the settings to the running configuration, click the Save icon.
Configure an IPv6 ACL
An IPv6 ACL consists of a set of rules that are matched sequentially against a packet.
When a packet meets the match criteria of a rule, the specified rule action (Permit or
Deny) is taken, and the additional rules are not checked for a match. You must specify
the interfaces to which an IPv6 ACL applies, as well as whether it applies to inbound or
outbound traffic.
Multiple steps are involved in defining an IPv6 ACL and applying it to the switch:
1. Add an IPv6 ACL ID (see Add an IPv6 ACL on page 680).
An IPv6 ACL must start with a name string that is up to 31 alphanumeric characters
in length. The name must start with an alphabetic character.
2. Create an IPv6 rule (see Configure rules for an IPv6 ACL on page 682).
3. Associate the IPv6 ACL with one or more interfaces (see Configure IP ACL interface
bindings on page 688).
