Page 332
Table 90. MSRP streams information (Continued)
Description
Field
If a failure occurred, the number that represents the reason for the failure. The
switch supports the following codes:
• 1: Insufficient bandwidth
• 3: Insufficient bandwidth for the traffic class
• 5: Stream destination address is already in use
• 7: Reported latency changed
• 8: Egress port is not capable of audio video bridging (AVB)
• 9: Use a different destination address (for example, if the MAC DA hash
table is full)
• 12: Cannot store destination address (for example, if the device ran out of
MAC DA resources)
• 13: Requested priority is not an SR class priority
• 14: MaxFrameSize is too large for media
• 15: msrpMaxFanInPorts limit was reached
• 16: Changes in FirstValue for a registered StreamID
• 17: VLAN is blocked on this egress port (Registration Forbidden)
Received Failure Information
Failure Code
If a failure occurred, the MAC address of the device on which the failure
occurred.
Received Failure Information
Bridge MAC
The interface on which the talker is present.
Talker Interface
The interface on which listeners are present.
Listeners
Loop protection
Loop protection can detect physical and logical loops between Ethernet ports on a
device.
About loop protection
Loops inside a network are costly because they consume resources and reduce the
performance of the network. Detecting loops manually can be cumbersome.
