Table 75. MVR statistics information

Definition

Field

The number of received IGMP queries.

IGMP Query Received

The number of received IGMP V1 reports.

IGMP Report V1 Received

The number of received IGMP V2 reports.

IGMP Report V2 Received

The number of received IGMP leaves.

IGMP Leave Received

The number of transmitted IGMP queries.

IGMP Query Transmitted

The number of transmitted IGMP V1 reports.

IGMP Report V1 Transmitted

The number of transmitted IGMP V2 reports.

IGMP Report V2 Transmitted

The number of transmitted IGMP leaves.

IGMP Leave Transmitted

The number of IGMP packet receive failures.

IGMP Packet Receive Failures

The number of IGMP packet transmit failures.

IGMP Packet Transmit Failures

MAC address table

You can view or configure the MAC address table. This table contains information about
unicast entries for which the switch holds forwarding or filtering information. This
information lets the transparent bridging function determine how an incoming frame
must be propagated.

View, search, or clear the MAC address table

If you clear the MAC address entries in the MAC address table, only the dynamic entries
are removed.

To view, search, or clear the MAC address table:

1. Launch a web browser.

2. In the address field of your web browser, enter the IP address of the switch.

The login page displays.

3. Click the Main UI Login button.

Main User Manual

290

Configure Switching Information

AV Line of Fully Managed Switches M4250 Series Main User Manual
