6. Select whether to display physical interfaces, LAGs, or both by clicking one of the
following links above the table heading:
• 1: Only physical interfaces are displayed. This is the default setting.
• LAG: Only LAGs are displayed.
• All: Both physical interfaces and LAGs are displayed.
7. Select one or more interfaces by taking one of the following actions:
• To configure a single interface, select the check box associated with the interface,
or type the interface number in the Go To Interface field and click the Go button.
• To configure multiple interfaces with the same settings, select the check box
associated with each interface.
• To configure all interfaces with the same settings, select the check box in the
heading row.
8. Specify the following settings:
• Security Mode: Enable or disable the port security feature. The default is Disable.
• Max Learned MAC Address: Specify the maximum number of dynamically learned
MAC addresses. The default value is 4096. If you specify 0, the interface does not
learn any MAC addresses.
• Max Static MAC Address: Specify the maximum number of statically locked MAC
addresses. The default value is 48.
• Violation Shutdown: Enable or disable shutdown if a packet with a disallowed
MAC address is received. The default is Disable.
• Violation Traps: Enable or disable sending of violation traps if a packet with a
disallowed MAC address is received. The default is Disable.
9. Click the Apply button.
Your settings are saved.
10. To save the settings to the running configuration, click the Save icon.
Display learned MAC addresses and convert them to static
addresses
After you enabled port security globally (see Configure the global port security mode
on page 567) and enabled port security for specific interfaces (see Configure a port
security interface on page 568), you can convert a dynamically learned MAC address to
a statically locked address.
