For a single recurring timer schedule, you can add a daily, weekly, and monthly schedule
configuration. That is, these schedule configurations are not mutually exclusive but
complement each other.

To specify the settings for a timer schedule that uses a recurring pattern:

1. Launch a web browser.

2. In the address field of your web browser, enter the IP address of the switch.

The login page displays.

3. Click the Main UI Login button.

The main UI login page displays in a new tab.

4. Enter admin as the user name, enter your local device password, and click the Login

button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.

The System Information page displays.

5. Select System > Timer Schedule > Advanced > Timer Schedule Configuration.

The Timer Schedule Configuration page displays.

6. In the Timer Schedule Selection section, make your selections from the following

menus:

a. Timer Schedule Name: Select the name of the timer schedule that you want to

configure.
You can select only names of schedules that you created (see Create a timer
schedule
on page 144).

b. Timer Schedule Type: Select Periodic.

The fields in the Timer Schedule Configuration section might adjust to let you
configure a timer schedule with a recurrence pattern.

c. Timer Schedule Entry: To add a new entry, select new.

Selecting an existing entry lets you make changes to that entry.

7. In the Timer Schedule Configuration section, specify the recurrence pattern:

a. In the Time Start field, enter the time of day in the HH:MM format to specify when

the timer schedule must start.

b. In the Time End field, enter the time of day in the HH:MM format to specify when

the timer schedule must stop.
