• False: The interface is not a member of the downstream list for the group. This is
the default setting.
• True: The interface is a member of the downstream list for the group.
10. Click the Apply button.
Your settings are saved.
11. From the Upstream Interface menu, select if the interface is a member of the group’s
upstream list.
• False. The interface is not a member of the upstream list for the group. This is the
default setting.
• True: The interface is a member of the up stream list for the group.
12. Click the Apply button.
Your settings are saved.
The Link Status field shows whether the link for the corresponding interface or LAG
is up or down.
13. To save the settings to the running configuration, click the Save icon.
14. To refresh the page, click the Refresh button.
The following table describes the nonconfigurable fields that are displayed in the
Link Dependency Group Statistic section.
Table 48. Link dependency group statistic information
Description
Field
The group ID. The range is from 1 to 16.
Group ID
The action to be performed on downstream interfaces when all the
interfaces in the upstream list go down.
Link Action
The current state of the group.
Group State
The number of group transitions.
Group Transitions
The time of the last group transition.
Last Transition Time
Clear all interfaces in a link dependency group
You can clear all interfaces in a link dependency group. After you do so, the upstream
list and downstream list for the group do not include any interfaces.
