Page 243
5. Select Switching > STP > Advanced > STP Statistics.
The STP Statistics page displays.
6. Select whether to display physical interfaces, LAGs, or both by clicking one of the
following links above the table heading:
• 1: Only physical interfaces are displayed. This is the default setting.
• LAG: Only LAGs are displayed.
• All: Both physical interfaces and LAGs are displayed.
Your settings are saved.
7. To refresh the page, click the Refresh button.
The following table describes the nonconfigurable fields on the page.
Table 62. STP interface statistics information
Description
Field
The number of STP BPDUs received on the interface.
STP BPDUs Received
The number of STP BPDUs transmitted from the interface
STP BPDUs Transmitted
The number of RSTP BPDUs received on the interface.
RSTP BPDUs Received
The number of RSTP BPDUs transmitted from the interface.
RSTP BPDUs Transmitted
The number of MSTP BPDUs received on the interface.
MSTP BPDUs Received
The number of MSTP BPDUs transmitted from the interface.
MSTP BPDUs Transmitted
Configure the PVST/RPVST VLAN settings
You can configure the Per-VLAN Spanning Tree Protocol (PVST) and Rapid PVST (RPVST)
settings for a VLAN.
PVST and RPVST must be enabled. For more information, see Configure the STP settings
and display the STP status on page 226.
To configure the PVST/RPVST VLAN settings for the switch:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
The login page displays.
3. Click the Main UI Login button.
Main User Manual
243
Configure Switching Information
AV Line of Fully Managed Switches M4250 Series Main User Manual
