3. Click the Main UI Login button.

The main UI login page displays in a new tab.

4. Enter admin as the user name, enter your local device password, and click the Login

button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.

The System Information page displays.

5. Select System > Services > DHCP Server> DHCP Pool Options.

The DHCP Pool Options page displays.

6. From the Pool Name menu, select the pool name.

7. In the Option Code field, specify the option code configured for the pool.

The range is from 1 to 254. For information about options and their format, see
information about RFC 2132 at https://tools.ietf.org/html/rfc2132.

8. Form the Option Type menu, select one of the following option types for the pool:

• ASCII: Enter the information in the Option Value field in ASCII format.
• Hex: Enter the information in the Option Value field in hexadecimal format. The

possible formats are xx:xx and xxxx.xxxx.

• IP Address: In the Option Value field, enter an IPv4 address.

9. In the Option Value field, specify the option value for the pool according to your

selection in the previous step.

10. Click the Add button.

The option code is added for the pool.

11. To save the settings to the running configuration, click the Save icon.

Display DHCP server statistics

To display the DHCP server statistics:

1. Launch a web browser.

2. In the address field of your web browser, enter the IP address of the switch.

The login page displays.

3. Click the Main UI Login button.

The main UI login page displays in a new tab.
