maximum bandwidth configuration. It is effectively a second-level shaping
mechanism. The default value is 0. The value 0 means that the maximum is unlimited.

10. Click the Apply button.

Your settings are saved.

11. To save the settings to the running configuration, click the Save icon.

Configure CoS queue settings for an interface

You can define what a particular queue does by configuring switch egress queues. You
can control how much bandwidth is used by the queue, the queue depth during times
of congestion, and the scheduling of packet transmission from all queues on a port.
Each port contains its own CoS queue-related configuration.

For information about configuring CoS queue settings globally, see Configure the CoS
trust mode settings globally or for a specific interface
on page 455.

To configure the CoS queue settings for an interface:

1. Launch a web browser.

2. In the address field of your web browser, enter the IP address of the switch.

The login page displays.

3. Click the Main UI Login button.

The main UI login page displays in a new tab.

4. Enter admin as the user name, enter your local device password, and click the Login

button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.

The System Information page displays.

5. Select QoS > CoS > Advanced > Interface Queue Configuration.

The Interface Queue Configuration page displays.

6. Select whether to display physical interfaces, LAGs, or both by clicking one of the

following links above the table heading:

• 1 (the unit ID of the switch): Only physical interfaces are displayed. This is the

default setting.

• LAG: Only LAGs are displayed.
• All: Both physical interfaces and LAGs are displayed.

7. Select one or more interfaces by taking one of the following actions:
