To remove primary and secondary VLANs from a private VLAN isolated trunk
interface:

1. Launch a web browser.

2. In the address field of your web browser, enter the IP address of the switch.

The login page displays.

3. Click the Main UI Login button.

The main UI login page displays in a new tab.

4. Enter admin as the user name, enter your local device password, and click the Login

button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.

The System Information page displays.

5. Select Security > Traffic Control > Private VLAN > Private VLAN Isolated Trunk

Interface Configuration.
The Private VLAN Isolated Trunk Interface Configuration page displays.

6. From the Interface menu, select an interface or LAG for which you configured the

VLAN port mode as Isolated Trunk mode.
For more information about port VLAN modes, see Configure the private VLAN port
mode
on page 581.

7. Select the check box for the VLAN configuration.

8. Click the Delete button.

Your settings are saved.

The primary and secondary VLANs are removed from the selected interface. The
VLANs themselves are not deleted.

9. To save the settings to the running configuration, click the Save icon.

Configure native and allowed VLANs on a private VLAN
trunk interface

If you configure an interface as either a private VLAN promiscuous interface or a private
VLAN isolated trunk interface, you can also allow untagged traffic from a native VLAN
on the same trunk interface. By default, VLAN 1 is both the default and the native VLAN,
but you can configure another VLAN as the native VLAN (see Configure the switch port
mode settings for interfaces
on page 196).
