M4250-26g4f-poe+ (sku gsm4230p) – NETGEAR AV Line M4250 GSM4210PX 8-Port Gigabit PoE+ Compliant Managed AV Switch with SFP (220W) User Manual
Page 820
Table 185. Hardware technical specifications for model M4250-10G2XF-PoE++
Description
Feature
Eight PoE++ (802.3bt) 1GBASE-T RJ-45 ports
Two 1GBASE-T RJ-45 ports
Two 10G SFP+ fiber uplink ports.
Network interfaces
100–240V ~ 50–60Hz, 10A
AC power input
837.7W - 2859.91 BTU/hr
26.3W - 89.79 BTU/hr
18W - 61.45BTU/hr
Max PoE
No PoE
Standby
Power
consumption
720W
PoE power budget
17.32 in (440 mm)
1.70 in (43.2 mm), 1U
10.12 in (257 mm)
Width
Height
Depth
Dimensions
8.44 lb (3.830 kg)
Weight
M4250-26G4F-PoE+ (SKU GSM4230P)
The following table shows the specifications that are specific to model
M4250-26G4F-PoE+.
Table 186. Hardware technical specifications for model M4250-26G4F-PoE+
Description
Feature
24 PoE+ (802.3at) 1GBASE-T RJ-45 ports
Two 1GBASE-T RJ-45 ports
Four 1G SFP fiber uplink ports
Network interfaces
100–240V ~ 50–60Hz, 4.4A
AC power input
401W - 1369.01 BTU/hr
35.8W - 122.22 BTU/hr
23.4W - 79.89 BTU/hr
Max PoE
No PoE
Standby
Power
consumption
300W
PoE power budget
Main User Manual
820
Software Default Settings and
Hardware Specifications
AV Line of Fully Managed Switches M4250 Series Main User Manual
