Table 8. Switch statistics information

Description

Field

The ifIndex of the interface table entry associated with the processor
of this switch.

ifIndex

The total number of octets of data received by the processor (excluding
framing bits but including FCS octets).

Octets Received

The total number of packets (including broadcast packets and multicast
packets) received by the processor.

Packets Received Without Errors

The number of subnetwork-unicast packets delivered to a higher-layer
protocol.

Unicast Packets Received

The total number of packets received that were directed to a multicast
address. This number does not include packets directed to the
broadcast address.

Multicast Packets Received

The total number of packets received that were directed to the
broadcast address. This does not include multicast packets.

Broadcast Packets Received

The number of inbound packets that were discarded even though no
errors were detected to prevent their being deliverable to a
higher-layer protocol. A possible reason for discarding a packet could
be to free up buffer space.

Receive Packets Discarded

The total number of octets transmitted out of the interface, including
framing characters.

Octets Transmitted

The total number of packets transmitted out of the interface.

Packets Transmitted Without Errors

The total number of packets that higher-level protocols requested that
are transmitted to a subnetwork-unicast address, including those that
were discarded or not sent.

Unicast Packets Transmitted

The total number of packets that higher-level protocols requested that
are transmitted to a multicast address, including those that were
discarded or not sent.

Multicast Packets Transmitted

The total number of packets that higher-level protocols requested that
are transmitted to the broadcast address, including those that were
discarded or not sent.

Broadcast Packets Transmitted

The number of outbound packets that were discarded even though
no errors were detected to prevent their being deliverable to a
higher-layer protocol. A possible reason for discarding a packet could
be to free up buffer space.

Transmit Packets Discarded

The highest number of Forwarding Database Address Table entries
learned by this switch since the most recent reboot.

Most Address Entries Ever Used

The number of learned and static entries in the Forwarding Database
Address Table for this switch.

Address Entries in Use

The maximum number of virtual LANs (VLANs) allowed on this switch.

Maximum VLAN Entries
