Table 186. Hardware technical specifications for model M4250-26G4F-PoE+ (Continued)

Description

Feature

17.32 in (440 mm)
1.70 in (43.2 mm), 1U
10.12 in (257 mm)

Width
Height
Depth

Dimensions

9.47 lb (4.300 kg)

Weight

M4250-26G4XF-PoE+ (SKU GSM4230PX)

The following table shows the specifications that are specific to model
M4250-26G4XF-PoE+.

Table 187. Hardware technical specifications for model M4250-26G4XF-PoE+

Description

Feature

24 PoE+ (802.3at) 1GBASE-T RJ-45 ports
Two 1GBASE-T RJ-45 ports
Four 10G SFP+ fiber uplink ports

Network interfaces

100–240V ~ 50–60Hz, 6.4–2.5A

AC power input

614W - 2096.2 BTU/hr
46.8W - 159.78 BTU/hr
33.9W - 115.73 BTU/hr

Max PoE
No PoE
Standby

Power
consumption

480W

PoE power budget

17.32 in (440 mm)
1.70 in (43.2 mm), 1U
15.75 in (400 mm)

Width
Height
Depth

Dimensions

12.02 lb (5.453 kg)

Weight

M4250-26G4F-PoE++ (SKU GSM4230UP)

The following table shows the specifications that are specific to model
M4250-26G4F-PoE++.
