8. Select the Configuration Method DHCP or Manual radio button to specify the switch
startup action:
• DHCP: The switch requests IP address information from a DHCP server.
• Manual: The switch loads the IP address information that you specify:
• IP Address: Specify the IP address of the interface.
The default value is 169.254.100.100.
•
Subnet Mask: Specify the IP subnet mask for the interface. This is also referred
to as the subnet/network mask and defines the portion of the interface’s IP
address that is used to identify the attached network.
The default value is 255.255.0.0.
•
Gateway: Specify the gateway for the interface.
The default value is 0.0.0.0.
9. Click the Apply button.
Your settings are saved.
10. To save the settings to the running configuration, click the Save icon.
Note: If you need to reset the IPv4 management VLAN, in the Reset IPv4 Management
Interface section of the page, select the Set Management Interface to Default check
box and click the Apply button. Doing so deletes the port-based IPv4 management
interface configuration and sets the IPv4 management interface back to the default
VLAN 1.
The Current IPv4 Management Interface Status section displays the following
nonconfigurable fields.
Table 12. Nonconfigurable IPv4 management interface status information
Description
Field
Displays the current IPv4 management VLAN.
Management Interface
Indicates whether the link status is up or down.
Link State
Indicates whether the link status is up or down for the management
interface.
Routing Interface Status
The MAC address assigned to the management interface.
MAC Address
Indicates whether the IP address configuration method is DHCP or manual.
IP Address Configuration Method
The IP address of the management interface.
IP Address
