5. Select System > LLDP > Local Device Information.

The Local Device Information page displays.

6. From the Interface menu, select an interface on which the transmission of LLDP

frames is enabled.

7. To refresh the page, click the Refresh button.

The following table describes the nonconfigurable fields on the page.

Table 42. LLDP local device information

Description

Field

The switch identifier is the MAC address of the switch (see the following

field).

Chassis ID Subtype

The MAC address of the switch.

Chassis ID

The port identifier is the MAC address of the interface (see the following

field).

Port ID Subtype

The MAC address of the interface on the switch.

Port ID

The system name, if any, of the switch.

System Name

The description of the switch.

System Description

The interface name, if any, of the interface on the switch.

Port Description

The system capabilities of the switch.

System Capabilities Supported

The system capabilities of the switch that are enabled.

System Capabilities Enabled

The type of the management IP address of the switch.

Management Address Type

The advertised management IP address of the switch.

Management Address

Display LLDP remote device information

You can display LLDP remote device information, which is information that the device
that is connected to an interface advertises.

To display LLDP remote device information:

1. Launch a web browser.

2. In the address field of your web browser, enter the IP address of the switch.

Main User Manual

166
