The following table describes the nonconfigurable fields on the page.

Table 111. IGMP routing interface statistics information

Description

Field

The interface on which IGMP is enabled.

Interface

The IP address of the interface.

IP Address

The subnet mask for the IP address of the interface.

Subnet Mask

The operational state of IGMP on the interface (Operational or

Non-Operational).

Protocol State

The address of the IGMP querier on the IP subnet to which the interface

is attached.

Querier IP

Indicates if the interface is in querier or non-querier mode.

Querier Status

The period in seconds since the IGMP interface querier was last changed.

Querier Up Time

The period in seconds remaining before the other querier present timer

expires. If the switch is the querier, this is zero.

Querier Expiry Time

The number of queries that were received on the interface with an IGMP

version that does not match the IGMP version configured for the interface,

over the lifetime of the entry. IGMP requires that all routers or routing

interfaces on a LAN are configured to run the same version of IGMP.

Therefore, a configuration error is indicated if any queries are received

with the wrong version number.

Wrong Version Queries Received

The number of times a group membership was added on the interface;

that is, the number of times an entry for the interface was added to the

cache table. This gives an indication of the amount of IGMP activity on the

interface.

Number of Joins Received

The current number of entries for the interface in the cache table.

Number of Groups

Display the IGMP groups and search the IGMP group
database

You can display the IGMP group information and search the IGMP group database by
interface or by group.
