NETGEAR AV Line M4250 GSM4210PX 8-Port Gigabit PoE+ Compliant Managed AV Switch with SFP (220W) User Manual
Page 270
To configure MLD snooping automatically:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
The login page displays.
3. Click the Main UI Login button.
The main UI login page displays in a new tab.
4. Enter admin as the user name, enter your local device password, and click the Login
button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.
The System Information page displays.
5. Select Switching > Multicast > MLD Snooping > Configuration.
The Configuration page displays.
6. Select the MLD Plus Mode Enable or Disable radio button.
If enabled, the following MLD snooping modes are automatically enabled:
•
MLD Snooping Admin mode
•
Exclude Mrouter Interface Mode
The default is Enable.
If disabled, these MLD snooping modes are automatically disabled.
Note: For information about other settings on the page, see Configure MLD
snooping manually on page 271.
7. Click the Apply button.
Your settings are saved.
8. To save the settings to the running configuration, click the Save icon.
9. To refresh the page, click the Refresh button.
The following table describes the nonconfigurable fields on the page.
Main User Manual
270
Configure Switching Information
AV Line of Fully Managed Switches M4250 Series Main User Manual
