NETGEAR AV Line M4250 GSM4210PX 8-Port Gigabit PoE+ Compliant Managed AV Switch with SFP (220W) User Manual
Page 436
8. In the Priority field, specify the priority for the BSR candidate.
The range is from 0 to 255. The default is 0.
9. In the Advertisement Interval field, specify the period in seconds between
advertisements.
The range is from 1 to 16383. The default is 60.
10. Click the Apply button.
Your settings are saved.
11. To save the settings to the running configuration, click the Save icon.
12. To refresh the page, click the Refresh button.
The following table describes the nonconfigurable fields on the page.
Table 123. IPv6 PIM BSR candidate configuration information
Description
Field
The time (in hours, minutes and seconds) after which the learned elected
BSR expires.
BSR Expiry Time (hh:mm:ss)
The IPv6 address of the elected BSR.
IP Address
The time (in hours, minutes, and seconds) after which the next bootstrap
message is due from the BSR.
Next bootstrap Message
(hh:mm:ss)
The time (in hours, minutes, and seconds) after which the next candidate
RP advertisement is sent.
Next Candidate RP Advertisement
(hh:mm:ss)
Delete an IPv6 PIM bootstrap router candidate configuration
You can delete an IPv6 PIM bootstrap router (BSR) candidate configuration from an
interface.
To delete an IPv6 PIM BSR candidate configuration from an interface:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
The login page displays.
3. Click the Main UI Login button.
The main UI login page displays in a new tab.
Main User Manual
436
Configure Multicast Routing
AV Line of Fully Managed Switches M4250 Series Main User Manual
