Page 242
Table 61. MST interface configuration information (Continued)
Description
Field
The bridge identifier of the root bridge, which is created by using the
bridge priority and the base MAC address of the bridge
Designated Root
The path cost offered to the LAN by the designated port.
Designated Cost
The bridge identifier of the bridge with the designated port. This identifier
is created from the bridge priority and the base MAC address of the
bridge.
Designated Bridge
The port identifier on the designated bridge that offers the lowest cost
to the LAN. This identifier is created from the port priority and the interface
number of the port.
Designated Port
Indicates if the interface is in a loop-inconsistent state. (False or True.)
Loop Inconsistent State
The number of times the interface transitioned into the loop-inconsistent
state.
Transitions Into Loop Inconsistent
State
The number of times the interface transitioned out of the loop-inconsistent
state.
Transitions Out Of Loop
Inconsistent State
Display the STP interface statistics
You can display information about the number and type of bridge protocol data units
(BPDUs) that are transmitted and received on each interface.
To display the STP interface statistics:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
The login page displays.
3. Click the Main UI Login button.
The main UI login page displays in a new tab.
4. Enter admin as the user name, enter your local device password, and click the Login
button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.
The System Information page displays.
