13. If you select Encrypt from he Authentication Type menu, in the Authentication Key

ID field, enter the RIP authentication Key ID for the interface.
The key ID can from 0 to 255.

14. Click the Apply button.

Your settings are saved.

15. To refresh the page, click the Refresh button.

16. To save the settings to the running configuration, click the Save icon.

The following table describes the nonconfigurable fields on the page.

Table 106. RIP interface configuration information

Description

Field

The number of RIP response packets received by the RIP process that
were subsequently discarded for any reason.

Bad Packets Received

The number of routes in valid RIP packets that were ignored for any reason
(for example, unknown address family, or invalid metric).

Bad Routes Received

The number of triggered RIP updates sent on the interface. This explicitly
does not include full updates sent containing new information.

Updates Sent

The IP address of the router interface.

IP Address

Indicates if the RIP router interface is up or down.

Link State

Configure the RIP route redistribution settings and display
the route redistribution summary

You can configure the RIP route redistribution settings and display the route redistribution
summary.

To configure RIP route redistribution settings and display the route redistribution
summary:

1. Launch a web browser.

2. In the address field of your web browser, enter the IP address of the switch.

The login page displays.

3. Click the Main UI Login button.

The main UI login page displays in a new tab.
