• Routing VLAN: The primary IP address of a VLAN routing interface is used as the

source address.

• Routing loopback interface: The primary IP address of a routing loopback

interface is used as the source address.

• Tunnel interface: The IPv6 tunnel interface.
• Service port: The management port source IP address is used as the source

address.

By default, VLAN 1 is used as the source interface.

7. Click the Apply button.

Your settings are saved.

8. To save the settings to the running configuration, click the Save icon.

The following table describes the nonconfigurable fields on the page.

Table 173. sFlow agent information

Description

Field

The version and implementation of the MIB. The agent version consists of the
following components:
• MIB version: For example, 1.3.

• Organization: NETGEAR, Inc.

• Revision: For example, 13.0.2.10.

Agent Version

The IP address associated with the agent. The IP address depends on your
selection of the source interface.

Agent Address

Configure an sFlow receiver

You can configure one or more devices that must function as sFlow receivers. The sFlow
source interface provides the connection to these devices.

To configure an sFlow receiver:

1. Launch a web browser.

2. In the address field of your web browser, enter the IP address of the switch.

The login page displays.

3. Click the Main UI Login button.

The main UI login page displays in a new tab.

Main User Manual

727

Monitor the Switch and Network

AV Line of Fully Managed Switches M4250 Series Main User Manual
