Remove a udp switch configuration – NETGEAR AV Line M4250 GSM4210PX 8-Port Gigabit PoE+ Compliant Managed AV Switch with SFP (220W) User Manual
Page 122
The main UI login page displays in a new tab.
4. Enter admin as the user name, enter your local device password, and click the Login
button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.
The System Information page displays.
5. Select System > Services > UDP Relay > UDP Relay Interface Configuration.
The page UDP Relay Interface Configuration page displays.
6. From the Interface menu, select the interface or VLAN.
7. Change the settings as needed.
For more information about the settings, see Add a UDP interface configuration on
page 120.
8. Click the Apply button.
Your settings are saved.
9. To save the settings to the running configuration, click the Save icon.
Remove a UDP switch configuration
To remove a UDP switch configuration:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
The login page displays.
3. Click the Main UI Login button.
The main UI login page displays in a new tab.
4. Enter admin as the user name, enter your local device password, and click the Login
button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.
The System Information page displays.
5. Select System > Services > UDP Relay > UDP Relay Interface Configuration.
The page UDP Relay Interface Configuration page displays.
6. From the Interface menu, select the interface or VLAN.
Main User Manual
122
Configure Switch System
Information
AV Line of Fully Managed Switches M4250 Series Main User Manual
