9. To save the settings to the running configuration, click the Save icon.

Display the IPv6 and ICMPv6 statistics for an IPv6 routing
interface

You can display the IPv6 and ICMPv6 statics for an IPv6 routing interface.

To display the IPv6 and ICMPv6 statistics for an IPv6 routing interface:

1. Launch a web browser.

2. In the address field of your web browser, enter the IP address of the switch.

The login page displays.

3. Click the Main UI Login button.

The main UI login page displays in a new tab.

4. Enter admin as the user name, enter your local device password, and click the Login

button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.

The System Information page displays.

5. Select Routing> IPv6 > Advanced > Statistics.

The Statistics page displays.

6. From the Interface menu, select the IPv6 routing interface.

7. To refresh the page, click the Refresh button.

The following table describes the nonconfigurable fields on the page.

Table 99. IPv6 interface statistics information

Description

Field

The total number of input datagrams received by the interface, including

those received in error.

Total Datagrams Received

The total number of datagrams successfully delivered to IPv6

user-protocols (including ICMP). This counter is incremented at the

interface to which these datagrams were addressed, which might not

be the input interface for some of the datagrams.

Received Datagrams Locally

Delivered
