To configure the switch port mode settings for interfaces:

1. Launch a web browser.

2. In the address field of your web browser, enter the IP address of the switch.

The login page displays.

3. Click the Main UI Login button.

The main UI login page displays in a new tab.

4. Enter admin as the user name, enter your local device password, and click the Login

button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.

The System Information page displays.

5. Select Switching > VLAN > Advanced > VLAN Trunking Configuration.

The VLAN Trunking Configuration page displays.

6. Select whether to display physical interfaces, LAGs, or both by clicking one of the

following links above the table heading:

• 1: Only physical interfaces are displayed. This is the default setting.
• LAG: Only LAGs are displayed.
• All: Both physical interfaces and LAGs are displayed.

7. Select one or more interfaces by taking one of the following actions:

To configure a single interface, select the check box associated with the interface,

or type the interface number in the Go To Interface field and click the Go button.

To configure multiple interfaces with the same settings, select the check box

associated with each interface.

To configure all interfaces with the same settings, select the check box in the

heading row.

8. From the Switch port Mode menu, select one of the following:

• Access: Select this mode if the interface is connected to end devices. Access

interfaces participate in one VLAN only. They accept both tagged and untagged
packets, but always transmit untagged packets.

• General: Select this mode so that you can configure the interface. You can

configure the general port VLAN attributes, such as membership (see Configure
membership interfaces for a VLAN
on page 199) and PVID, tagging, ingress filter,
and so on (see Change the port VLAN ID settings on page 202). This is the default
selection.
