Table 86. MVRP statistics information (Continued)

Description

Field

The number of MMRP frames that the switch did not transmit.

Transmission Failures

The number of MMRP messages that were not added to the queue.

Message Queue Failures

MVRP Statistics

The interface for which information is displayed.

Interface

The number of MVRP frames that were received on the interface.

Frames Received

The number of MVRP frames with bad headers that were received on the
interface.

Bad Header

The number of MVRP frames with bad PDUs body formats that were received
on the interface.

Bad Format

The number of MVRP frames that were transmitted on the interface.

Frames Transmitted

The number of MVRP frames that the interface failed to transmit.

Transmission Failures

The number of MVRP frames that failed to register on a device or particular
interface.

Registration Failures

View or clear MSRP statistics

You can view and clear information about the MSRP frames transmitted and received
by the switch and by each interface.

To view and clear MSRP statistics:

1. Launch a web browser.

2. In the address field of your web browser, enter the IP address of the switch.

The login page displays.

3. Click the Main UI Login button.

The main UI login page displays in a new tab.

4. Enter admin as the user name, enter your local device password, and click the Login

button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.

The System Information page displays.

5. Select Switching > MRP > Advanced > MSRP Statistics.

The MSRP Statistics page displays.
