4. Enter admin as the user name, enter your local device password, and click the Login
button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.
The System Information page displays.
5. Select Security > Control > IP Source Guard > Interface Configuration.
The Interface Configuration page displays.
6. Select whether to display physical interfaces, LAGs, or both by clicking one of the
following links above the table heading:
• 1 (the unit ID of the switch): Only physical interfaces are displayed. This is the
default setting.
• LAG: Only LAGs are displayed.
• All: Both physical interfaces and LAGs are displayed.
7. Select one or more interfaces by taking one of the following actions:
• To configure a single interface, select the check box associated with the port, or
type the port number in the Go To Interface field and click the Go button.
• To configure multiple interfaces with the same settings, select the check box
associated with each interface.
• To configure all interfaces with the same settings, select the check box in the
heading row.
8. From the IPSG Mode menu, specify the administrative mode of IPSG on the interface:
• Enable: IPSG is enabled on the interface. The IP address of the source is not in
DHCP snooping binding database, packets are not forwarded.
• Disable: IPSG is disabled on the interface. The default is Disable.
9. From the IPSG Port Security menu, specify the administrative mode of IPSG port
security on the interface:
• Enable: IPSG port security is enabled on the interface. Packets are not forwarded
if the MAC address of the source is not in forwarding database table or the DHCP
snooping binding database. To enforce filtering based on the MAC address, you
must also configure the following features:
•
Enable port security globally (see Configure the global port security mode on
page 567).
•
Enable port security on the interface (see Configure a port security interface
on page 568).
• Disable: IPSG port security is disabled on the interface. The default is Disable.
