12. Click the Apply button.

Your settings are saved.

13. To save the settings to the running configuration, click the Save icon.

14. To refresh the page, click the Refresh button.

The following table describes the nonconfigurable fields on the page.

Table 67. IGMP snooping configuration information

Description

Field

The number of multicast control frames that are processed by the switch.

Multicast Control Frame Count

The interfaces on which IGMP snooping is enabled.

Interfaces Enabled for IGMP

Snooping

Indicates if IGMP snooping is globally enabled or disabled on the switch.

Operational Mode

The VLANs on which IGMP snooping is enabled.

VLAN IDs Enabled For IGMP

Snooping

Configure the IGMP snooping settings for interfaces

You can configure the IGMP snooping settings for interfaces.

To configure the IGMP snooping settings for interfaces:

1. Launch a web browser.

2. In the address field of your web browser, enter the IP address of the switch.

The login page displays.

3. Click the Main UI Login button.

The main UI login page displays in a new tab.

4. Enter admin as the user name, enter your local device password, and click the Login

button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.

The System Information page displays.

5. Select Switching > Multicast > IGMP Snooping > Interface Configuration.

The Interface Configuration page displays.
