To display the statistics for the MLD proxy interface:

1. Launch a web browser.

2. In the address field of your web browser, enter the IP address of the switch.

The login page displays.

3. Click the Main UI Login button.

The main UI login page displays in a new tab.

4. Enter admin as the user name, enter your local device password, and click the Login

button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.

The System Information page displays.

5. Select Routing > IPv6 Multicast > MLD > Proxy Interface Statistics.

The Proxy Interface Statistics page displays.

6. To refresh the page, click the Refresh button.

The following table describes the nonconfigurable fields on the page.

Table 129. MLD proxy interface statistics information

Description

Field

The interface on which MLD proxy packets are received.

Proxy Interface

The version of MLD proxy packets received.

Version

The number of MLD proxy queries received.

Queries Received

The number of MLD proxy reports received.

Reports Received

The number of MLD proxy reports sent.

Reports Sent
