8192

4096

0

20480

16384

12288

32768 (default)

28672

24576

45056

40960

36864

57344

53248

49152

61440

The default value is 32768. If the value that you enter is not among the specified
values, the value is automatically rounded off to the nearest valid value.

12. Click the Add button.

PVST/RPVST VLAN configuration is added.

13. To save the settings to the running configuration, click the Save icon.

Change a PVST/RPVST VLAN configuration

You can change an existing PVST/RPVST VLAN configuration.

To change an existing PVST/RPVST VLAN configuration:

1. Launch a web browser.

2. In the address field of your web browser, enter the IP address of the switch.

The login page displays.

3. Click the Main UI Login button.

The main UI login page displays in a new tab.

4. Enter admin as the user name, enter your local device password, and click the Login

button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.

The System Information page displays.

5. Select Switching > STP > Advanced > PVST VLAN.

The PVST VLAN page displays.

6. Select the check box that is associated with the PVST/RPVST VLAN configuration.

7. Change the settings as needed.
