Description
Inverts the transmitter pre-emphasis pretap. Specifies the TX pre-emphasis pretap setting value, including
inversion.
Options
• TRUE
• FALSE
Assign To
Pin - TX serial data
Related Information
This solution provides the mapping of the Transceiver Toolkit pretap settings to the Quartus II
transceiver QSF assignment.
XCVR_TX_PRE_EMP_PRE_TAP
Pin Planner and Assignment Editor Name
Transmitter Pre-emphasis Pre Tap
Description
Specifies the pre-tap pre-emphasis setting.
Note: This parameter must be set in conjunction with
XCVR_TX_VOD
,
XCVR_TX_PRE_EMP_1ST_POST_TAP
,
and
XCVR_TX_PRE_EMP_2ND_POST_TAP
. All combinations of these settings are not legal. Refer to the
Stratix V Device Datasheet for more information.
Options
0–15
Assign To
Pin - TX serial data
Related Information
XCVR_TX_RX_DET_ENABLE
Pin Planner and Assignment Editor Name
Transmitter Receiver Detect Block Enable
Description
Enables or disables the receiver detector circuit at the transmitter.
19-50
XCVR_TX_PRE_EMP_PRE_TAP
UG-01080
2015.01.19
Altera Corporation
Analog Parameters Set Using QSF Assignments
