Table 12-5: TX PLL Parameters
The following table describes how you can define multiple TX PLLs for your Native PHY. The Native PHY GUI
provides a separate tab for each TX PLL.
Parameter
Range
Description
PLL type
CMU
ATX
You can select either the CMU or ATX PLL. The
CMU PLL has a larger frequency range than the ATX
PLL. The ATX PLL is designed to improve jitter
performance and achieves lower channel-to-channel
skew; however, it supports a narrower range of data
rates and reference clock frequencies. Another
advantage of the ATX PLL is that it does not use a
transceiver channel, while the CMU PLL does.
Because the CMU PLL is more versatile, it is specified
as the default setting. An error message displays in the
message pane if the settings chosen for Data rate and
Input clock frequency are not supported for selected
PLL.
PLL base data rate
Device Dependent Shows the base data rate of the clock input to the TX
PLL.The PLL base data rate is computed from the
TX local clock division factor multiplied by the Data
rate. Select a PLL base data rate that minimizes the
number of PLLs required to generate all the clocks for
data transmission. By selecting an appropriate PLL
base data rate, you can change data rates by changing
the TX local clock division factor used by the clock
generation block.
Reference clock frequency
Device Dependent Specifies the frequency of the reference clock for the
Selected reference clock source index you specify.
You can define a single frequency for each PLL. You
can use the Transceiver Reconfiguration Controller
shown in Stratix V Native Transceiver PHY IP Core
to dynamically change the reference clock input to the
PLL.
Note that the list of frequencies updates dynamically
when you change the Data rate.
The Input clock frequency drop down menu is
populated with all valid frequencies derived as a
function of the data rate and base data rate. However,
if fb_compensation is selected as the bonding mode
then the input reference clock frequency is limited to
the data rate divided by the PCS-PMA interface
width.
Selected reference clock
source
0-4
You can define up to 5 frequencies for the PLLs in
your core. The Reference clock frequency selected
for index 0 , is assigned to TX PLL<0>. The Reference
clock frequency selected for index 1 , is assigned to
TX PLL<1>, and so on.
